Camera Image Sensor 1/2.8" Progressive Scan CMOS Min. Illumination Color: 0.01 Lux @(F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON) Shutter Speed 1/3 s to 1/100, 000 s, support slow shutter Slow Shutter Yes Auto-Iris No Day & Night IR cut filter Digital Noise Reduction 3D DNR WDR 120dB WDR Angle Adjustment Pan: 0° to 360°, tilt: 0° to 90°, rotation: 0° to 360° Lens Focal Length 2.7 to 13.5 mm Aperture F1.6 Focus Auto FOV Horizontal field of view: 98°to 34° Vertical field of view: 51°to 19° Diagonal field of view: 115°to 40° Lens Mount Φ14 IR IR Range Up to 60 m Wavelength 850 nm Compression Standard Video Compression Main stream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG Third stream:H.265/H.264 H.264 Type Baseline Profile/Main Profile/High Profile H.264+ Main stream supports H.265 Type Main Profile H.265+ Main stream supports Video Bit Rate 32 Kbps to 8 Mbps Audio Compression G.711/G.722.1/G.726/MP2L2/PCM Audio Bit Rate 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) Smart Feature-set Region of Interest 1 fixed region for main stream and sub-stream Behavior Analysis Line crossing detection, intrusion detection, Face Detection Yes Image Max. Resolution 1920 × 1080 Main Stream Max. Frame Rate 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) Sub-stream Max. Frame Rate 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) Third steam Max. Frame Rate 50Hz:CIF@1fps 60Hz:CIF@1fps Image Enhancement BLC, 3D DNR,HLC Image Settings Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser Specification
